Home > Rene 41 Sheets and Plates
Tanvir Nickel Alloys remains a trusted name in manufacturing and supplying high performance nickel alloys in Cairo, Egypt. Known for its accuracy and quality, the company specializes in providing premium products such as René 41 Sheets and Plates. Made from high strength, heat resistant alloys, these sheets and plates are ideal for aerospace, chemical and industrial applications. Tanvir Nickel Alloys is committed to excellence, ensuring sustainability and reliability for its global customers.
Tanvir Nickel Alloys is a reliable **Rene 41 Sheets and Plates Manufacturer in Cairo, Egypt**, focusing on providing top-notch nickel-based superalloy materials that can handle extreme temperatures and stress. Known for their remarkable strength, creep resistance, and oxidation stability at high temperatures, Rene 41 sheets and plates are perfect for aerospace, power generation, and cutting-edge industrial applications. Tanvir Nickel Alloys is committed to delivering materials that meet the strict standards of advanced engineering projects, ensuring precise thickness, excellent surface quality, and adherence to international standards like AMS and ASTM.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
The Rene 41 sheets and plates produced by Tanvir Nickel Alloys are primarily made of nickel, with added cobalt, chromium, titanium, and molybdenum. This intricate alloy mix offers impressive tensile strength, outstanding fatigue resistance, and remarkable stability at temperatures reaching around 700°C (1290°F). Thanks to its unique microstructure, Rene 41 maintains its mechanical properties even under prolonged high-temperature exposure, making it ideal for components that experience thermal cycling and mechanical stress. These sheets and plates come in various thicknesses and sizes, available in both solution-annealed and age-hardened forms to meet specific application needs.
Contact us to get a quick quote for your requirement.
Rene 41 sheets and plates from Tanvir Nickel Alloys are extensively used in critical applications that demand high-temperature strength and reliability. In the **aerospace industry**, they find their place in turbine blades, jet engine components, and rocket motor parts. The **power generation sector** relies on Rene 41 for gas turbines and heat exchangers that endure extreme heat. Moreover, these sheets and plates are utilized in **high-performance automotive engines**, **chemical processing equipment**, and **industrial gas turbines**. With a promise of consistent quality, precise manufacturing, and timely delivery, Tanvir Nickel Alloys has become a go-to choice for many in the industry.
