Tanvir Nickel Alloys, located in Cairo, Egypt, stands out as a leading manufacturer and supplier of high-performance Nimonic 80A Bars, specifically designed for industries that demand exceptional heat and corrosion resistance. With a solid reputation for their expertise in nickel-based superalloys, the company produces precision-engineered bars that adhere to strict quality standards. Nimonic 80A is well-known for its ability to maintain strength and stability even in extreme temperatures, making it an essential material for sectors like aerospace, power generation, and chemical processing. Thanks to their advanced production facilities and thorough quality control measures, Tanvir Nickel Alloys consistently delivers reliable, durable, and high-performance Nimonic 80A Bars to clients around the globe.
Nimonic 80A Bars are crafted from nickel-chromium-based superalloys, enhanced with cobalt, titanium, and aluminum. This specific blend offers excellent creep resistance, impressive tensile strength, and remarkable fatigue endurance at high temperatures. The alloy showcases outstanding oxidation resistance up to 700–750°C, maintaining its structural integrity even in challenging conditions. Heat treatment further boosts its mechanical properties, ensuring exceptional hardness and stability. Additionally, Nimonic 80A Bars are resistant to thermal shock and stress corrosion cracking, making them perfect for long-term use in high-stress, high-temperature environments.
| Standards : | Nimonic 80A Rod, Bar : BS 3076 HR1, ASTM B 637, AECMA PrEn2188, AECMA PrEn2189, AECMA PrEn 2190, AECMA PrEn 2396, AECMA PrEn2397, AIR 9165-37 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | Al | B | C | Cr | Co | Cu | Fe | Mn | Ni | P | Si | S |
| Nimonic 80A | 1 – 1.8 | 0.008 max | 0.1 max | 18 – 21 | 0.2 max | 0.2 max | 3 max | 1 max | Balance | 0.045 max | 1 max | 0.015 max |
| Grade | Condition | Ultimate Tensile Strength MPA | Yield Strength MPA | Elongation on 4D (min) | Hardness min |
| Nimonic 80A | Solution Annealed & Precipatation Treated (aged) | 994 | 616 | 20 | 300 HV |
At Tanvir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic 80A Bar in Cairo, Egypt, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Egypt, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These bars find extensive applications in aerospace components like turbine blades, discs, and shafts, thanks to their high-temperature strength and durability. In the power generation sector, they are utilized in gas turbines, boilers, and heat exchangers, where consistent performance at elevated temperatures is crucial. The chemical and petrochemical industries also rely on Nimonic 80A Bars for reactor parts and furnace components that need to withstand oxidation and corrosion. Their unique combination of toughness, fatigue resistance, and thermal stability makes them ideal for automotive turbochargers, nuclear reactors, and other high-performance engineering applications, where reliability is key.
