Tanvir Nickel Alloys, based in Cairo, Egypt, is a reliable manufacturer and supplier of Copper Nickel 90/10 Forged Fittings, designed to offer exceptional corrosion resistance and mechanical strength in tough marine and industrial settings. These fittings are crafted using cutting-edge forging techniques and rigorous quality control measures, ensuring they meet international standards for durability and dependability. Tanvir Nickel Alloys caters to various industries, including shipbuilding, offshore oil and gas, desalination, and power generation, providing forged fittings that guarantee secure, leak-proof connections in critical piping and fluid systems.
Copper Nickel 90/10 Forged Fittings are made from an alloy that contains about 90% copper and 10% nickel, with small amounts of iron and manganese added to enhance strength and corrosion resistance. These fittings typically showcase tensile strengths between 245 and 310 MPa and yield strengths from 69 to 125 MPa. The forging process improves the grain structure, offering excellent resistance to pitting, stress corrosion cracking, and biofouling, particularly in seawater and brackish water environments. Their mechanical integrity and thermal stability make them ideal for high-pressure and high-temperature applications.
Cupro Nickel Forged Fittings Specification : ASTM B467 / ASME SB467
Dimension Standard : ASME B16.11, MSS-SP-79, MSS-SP-83, MSS-SP-95, MSS-SP-97, BS3799
Size : 1/8″ NB to 4″ NB
Type : Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure : Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
|---|---|---|---|---|---|---|
| Cupro Nickel 90/10 | 88.6 | 1.0 max | 0.05 max | 9 – 11 max | 1.8 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
At Tanvir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 90/10 Forged Fittings in Cairo, Egypt, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Egypt, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You’ll find Copper Nickel 90/10 Forged Fittings commonly used in seawater piping systems, ballast water lines, heat exchangers, and fire-fighting systems in marine and offshore installations. They are also vital components in desalination plants, chemical processing facilities, and coastal power stations, where corrosion resistance and mechanical reliability are essential. With their long service life, straightforward installation, and low maintenance needs, Copper Nickel 90/10 Forged Fittings are a fantastic choice for engineers and designers tackling challenging service conditions.
