Tanvir Nickel Alloys stands out as a top-notch manufacturer and supplier of Alloy C263 Sheets and Plates in Cairo, Egypt. They’ve built a solid reputation for providing high-performance nickel-based superalloys that are designed to tackle the toughest applications. These sheets and plates are known for their remarkable strength, resistance to oxidation, and thermal stability, even at high temperatures. With a commitment to precision manufacturing and strict adherence to international quality standards, Tanvir Nickel Alloys delivers materials that you can count on to perform reliably in harsh operating conditions. Their Alloy C263 Sheets and Plates find a home in various industries, including aerospace, petrochemical, power generation, and marine, where durability, heat resistance, and top-notch mechanical integrity are crucial.
Alloy C263 Sheets and Plates are primarily made up of nickel (50–55%), chromium (19–21%), cobalt (19–21%), and molybdenum (5.6–6.1%), along with trace amounts of titanium, aluminum, carbon, and iron. This well-balanced chemical makeup gives the alloy exceptional strength, corrosion resistance, and oxidation resistance up to 800°C. It boasts a tensile strength of about 1000 MPa and shows excellent resistance to creep and rupture, even under high-stress conditions. Plus, it retains good ductility, weldability, and formability, making it a great choice for components that face both mechanical and thermal fatigue.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
At Tanvir Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Alloy C263 Sheets and Plates in Cairo, Egypt, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Egypt, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Alloy C263 Sheets and Plates are widely utilized in environments that experience high temperatures and significant stress. In the aerospace sector, they’re used for turbine components, combustion liners, and exhaust systems. In power generation and petrochemical facilities, you’ll find them in heat exchangers, reactors, and gas turbine parts that are exposed to oxidizing atmospheres. Their outstanding corrosion and thermal resistance also make them ideal for marine and chemical processing applications. Alloy C263 Sheets and Plates are highly regarded for their ability to maintain structural stability, reliability, and performance, even in extreme operational conditions.
